AC4262/120/PT1000 pH Sensor with HF-Resistant Glass
Place of Origin: Shanghai, china
Purpose: Industry, laboratory, other
Warranty period: one year
Support customization: OEM, ODM
Logo: ACITEK
Model: AC4262/120/PT1000
Type: pH sensor
Equipped with a rechargeable battery: No
Material: Glass
Length (Excludes Cable): 120mm
Diameter (External): 12mm
Product parameters
|
Digital or Analog |
Analog |
pH Sensing Technology |
Hydrofluoric Acid Resistant Glass Membrane (HF) |
|
pH Range |
0.00 – 14.00 |
Reference System |
Extra polymer electrolyte, open double junction, cartridge with silver-ion trap |
|
Operating Temperature (Fahrenheit) |
32 °F - 266 °F |
Operating Temperature (Celsius) |
0.0 °C - 130.0 °C |
|
Cable Connector |
VP8 |
Process Connection |
PG13.5 Thread |
|
Sterilizable/Autoclavable |
No |
Sensor Length |
120mm |
|
Operating Pressure (Bar) |
0 to 15 barg @ 25°C;0 to 7 barg @ 130°C |
Model Family |
AC4260 |
|
Temperature Sensor |
PT1000 |
Measurement Parameter |
pH/Temp |
|
Shaft Material |
Glass |
Operating Pressure (PSI) |
0 to 101 psig @ 266°F |
|
Refillable Electrolyte |
No |
Hazardous Area Approvals |
Yes |
|
Primary Media/Application |
Chemical Processes |
Hygienic/Biocompatibility Approvals |
No |
Product Introduction
Reliable, Long-Lasting pH Probe: The AC4262 is an analog, in-line pH probe with hydrofluoric acid resistant glass for demanding chemical applications.
Withstands Demanding Applications: The AC4262 uses a polymer reference system and HF resistant glass for precise pH measurement, even under difficult industrial conditions.
Accurate pH Measurement: The AC4262 provides a wide measurement range from 0-14 pH and can measure accurately in high temperature or high pressure environments.
Designed for Reliability: The AC4262 has a domed glass membrane that impedes bubble formation and an integrated temperature sensor to ensure reliable measurement.
